Kampa Dometic Ace AIR ALL-SEASON 400 XXL MH1009 9120000087 2020

KAMPA DOMETIC ACE AIR ALL-SEASON 400
Because of the success of the Ace AIR All-Season caravan awning Kampa Dometic have introduced the Motorhome version in 4 height sizes.
The All-Season material makes this the ultimate seasonal pitch awning for motorhomes and recommended for touring in high UV countries.
An awning that will be the envy of the site and with the multitude of accessories means you can personalise it into the perfect static holiday home
Being 3 metres deep with a ‘Dual Pitch’ roof that gives a more upright front, this awning provides a massive exterior living space.
Inside, the shaped front and large panoramic windows and skylights provide a light and airy environment for you to enjoy your views.
Easy to set up, the awning inflates for one point in minutes either with the manual pump provided or by using the optional Gale 12v pump.
The Motor Ace AIR All-Season has been designed to be set up for extended periods of time and every component has been selected to cope with extremes of weather.
The Four-Season fabric has been tested in the sunniest parts of Australia to ensure that it’s suitable for use in this awning.
Features
• Inflatable – Single Point inflation system
• Each tube can be isolated via isolation valves
• Weathershield™ Four-Season material
• Flame retardant and UV stabilised
• Seams sewn with waterproof thread
• Zip-out front and side panels
• Crystal Clear windows with curtains
• Quickpitch™­ guying system
• No-see-um mesh flyscreen on side doors
• Large flyscreen in right-hand side window
• Sealing bumper pads
• Complete with rear upright pole set and hand pump
• Complete with a Storm Tie Down Kit as standard.
• 4mm and 6mm Keder (beading) fitted

IMPORTANT MEASUREMENTS
REQUIRES: 400cm OF AWNING TRACK (The cassette blind must be at least 450cm in length)
PLEASE ENSURE THE CORRECT HEIGHT SIZE IS PURCHASED (From track of closed cassette awning to ground)
REQUIRES 12cm of CLEARANCE FROM TOP OF MOTORHOME DOOR TO THE TRACK OF THE CASSETTE AWNING (To prevent the door hitting the roof of the awning)

               Model                                    Code         Fits             Width     Depth          Pack Size cm        Weight             Min.Weight
Motor Ace AIR All-Season 400 S     MH1006  235 – 250 cm  400 cm   300 cm    97 x 47.5 + 108 x 20  28.0 + 9.8 kg    27.0 kg
Motor Ace AIR All-Season 400 L     MH1007  250 – 265 cm  400 cm   300 cm    97 x 48.5 + 108 x 20  28.6 + 9.8 kg     27.6 kg
Motor Ace AIR All-Season 400 XL   MH1008  265 – 280 cm  400 cm   300 cm    97 x 48.5 + 108 x 20  29.2 + 9.8 kg     28.2 kg
Motor Ace AIR All-Season 400 XXL MH1009 280 – 295 cm  400 cm   300 cm    97 x 49.0 + 108 x 20   29.6 + 9.8 kg    28.6 kg
All-Season Tall Annexe                    CE7378 –                       180 cm   200 cm    85 x 31                        12.0 kg                   –
Sun Wing 400 CE7026                                                                          250 cm    83 x 13                        16.3 kg                   –
